NBT118
IP20 Batten, Slim Design, CCT & Wattage Selectable Batten, 2ft~6ft
CCT and power switch selectable
Polycarbonate body and diffuser
Surface mounting for internal applications
| Code | NBT118-2ft | NBT118-4ft | NBT118-5ft | NBT118-6ft |
|---|---|---|---|---|
| Dimension(mm) | 600x74x23 | 1200x74x23 | 1500x74x23 | 1800x74x23 |
| Watt(W) | 20W | 40W | 50W | 60W |
| Rated Input Voltage | AC220-240V | AC220-240V | AC220-240V | AC220-240V |
| Light Source | 2835 | 2835 | 2835 | 2835 |
| SDCM | <6 | <6 | <6 | <6 |
| CCT(K) | 3000K/ 4000K/ 6000K | 3000K/ 4000K/ 6000K | 3000K/ 4000K/ 6000K | 3000K/ 4000K/ 6000K |
| CCT Selection DIP Switch | YES | YES | YES | YES |
| Luminous Flux (lm) | 2400 | 4800 | 6000 | 7200 |
| CRI | 80 | 80 | 80 | 80 |
| Beam Angle (°) | 120° | 120° | 120° | 120° |
| LED Driver | Driver built-in | Driver built-in | Driver built-in | Driver built-in |
| Dimming Option | NO | NO | NO | NO |
| Sensor | NO | NO | NO | NO |
| Emergency Kits | NO | NO | NO | NO |
| Electrical Class | Class II | Class II | Class II | Class II |
| Ingress Protection(IP Rating) | IP20 | IP20 | IP20 | IP20 |
| Impact Resistance(IK Rating) | IK06 | IK06 | IK06 | IK06 |
| Product Finishing | White | White | White | White |
| Optics Material | PC | PC | PC | PC |
| Housing Material | PC | PC | PC | PC |
| Lifetime (hr) | 25,000h | 25,000h | 25,000h | 25,000h |
| Glow wire test (°C) | 650°C | 650°C | 650°C | 650°C |
| Operating Temp.(°C) | -20°C~40°C | -20°C~40°C | -20°C~40°C | -20°C~40°C |
| Storage Temp.(°C) | -20°C~65°C | -20°C~65°C | -20°C~65°C | -20°C~65°C |
| Installation | Surface mounting | Surface mounting | Surface mounting | Surface mounting |
